Ball Screw CNC
Ball screws are widely used in CNC (Computer Numerical Control) machines. Precision ball screw CNC plays an important role in converting rotary motion into linear motion, ensuring CNC machines run accurately and have fast movements.
Description
1.Product introduction
Ball screws are widely used in CNC (Computer Numerical Control) machines. Precision ball screw CNC plays an important role in converting rotary motion into linear motion, ensuring CNC machines run accurately and have fast movements.
2.Product specification
Ball screw CNC set normally consists of ball screw, ball nut, nut housing (aluminum alloy or steel material), end supports (BKBF, EKEF, or FKFF), and coupling. Alternatively, a motor bracket can be used to connect the ball screw to a servo or stepper motor. We have standard end machining drawings like the following, or it is perfect to send us drawings.
3.Product Specification
|
Product Name |
ball screw CNC |
|
Series |
SFU,DFU,SFE,SFS,SFK,SFI |
|
Ball screw diameter/mm |
6mm,8mm,10mm,12mm,16mm,20mm,25mm,32mm,40mm,50mm,63mm,80mm,100mm |
|
Ball screw pitch/mm |
1mm,2mm,2.5mm,4mm,5mm,10mm,16mm,20mm,25mm,32mm,40mm |
|
Precision |
C7(50 μm in 300mm) and C5(18 μm in 300mm) |
|
Surface treatment |
Polish, nickel plating,black coated |
|
Material |
S55C,bearing steel |
|
Nut type |
With flange or without flange |
|
Color |
metal color,black or silver color |
|
Delivery time |
C7 precision is about one week, C7 precision is about 7-10 days |
|
End maching |
With or without end maching |
|
Drawings |
Available to provide drawings |
|
Package |
Carton or wooden box |
|
Payment term |
100% for small order. 30% advance payment, 70% left payment before shipment for bulk order. |
4.Workshop and office
5.Package
6.1 Q: What is the difference between C5 and C7 precision ball screw?
A: C5 precision is for grinding ball screw, with an accuracy of 18 μm in 300mm. C7 precision is for rolled ball screw, with an accuracy of 50 μm in 300mm. C5 precision is better and the price is higher.
6.2 Q: What is the delivery time for C5 and C7 precision ball screw?
A: Normally, the delivery time is about one week. For bulk orders, it is about 7-15 days.
6.3 Q: Do you produce samples for ball screws? Are they free or charge?
A: We can produce ball screw samples for testing purposes. They are charged.
6.4 Q: What payment methods can you provide?
A: We can provide TT payment, Alipay, WeChat Pay, etc.
